Introduction
1.1.1
Civil Engineering
and Development Department is the Project Proponent for the Project “Site Formation and Associated
Infrastructural Works for Development of Columbarium, Crematorium and Related
Facilities at Sandy Ridge Cemetery” (hereafter referred as “the
Project”). The Project is a Designated Project to be implemented under Environmental Permit No. EP-534/2017. The layout plan of the Project is shown in Appendix
A. To facilitate the Project management, the Project works were separated into three different Contracts which are described
below sub-sections.
1.1.2
Contract No. CV/2016/10 - Site
Formation and Associated Infrastructural Works for Development of Columbarium
at Sandy Ridge Cemetery (hereafter referred as “Contract 1”):-
Ÿ
Site formation of about 1.77 ha of land for the proposed pick-up
and drop-off area for shuttle bus operation;
Ÿ
Upgrading of a section of 900m existing Sha Ling Road from 3m wide
carriageway to 7.3m wide carriageway with footpath at both sides;
Ÿ
Construction of one EVA with a total length of about 160m;
Ÿ
Construction of noise barriers along Sha Ling Road;
Ÿ
Modification of junction between Man Kam To Road and Sha Ling
Road;
Ÿ
Construction of a new pick up / drop off point at Man Kam To Road;
Ÿ
Relocation and construction of a new refuse collection point near
junction between Man Kam To Road and Sha Ling Road;
Ÿ
Associated geotechnical works including cut and fill slopes, soil
nailing works and retaining structures;
Ÿ
Associated drainage, sewerage and waterworks along Sha Ling Road;
and
Ÿ
Associated landscaping works.
1.1.3
Contract
No. CV/2017/02 - Infrastructural Works at Man Kam To Road and Lin Ma Hang Road
for Development of Columbarium at Sandy Ridge Cemetery (hereafter referred as “Contract 2”):-
Ÿ
Construction of a new road connecting Columbarium site to
Crematorium site;
Ÿ
Construction of one EVA with a total length of about 300m;
Ÿ
Widening of a section of 1.4 km long Lin Ma Hang Road (between Man
Kam To Road and Ping Yuen River) from 6m wide carriageway to 7.3m with 2m width
footpath on both sides;
Ÿ
Provision of a pair of lay-by at Lin Ma Hang Road;
Ÿ
Construction of a new vehicular access connecting the Sheung Shui Landmark North PTI
and Lung Sum Avenue;
Ÿ
Construction of covered walkway along Fanling Station Road;
Ÿ
Removal of planters and central divider along Fanling Station Road
and San Wan Road;
Ÿ
Associated drainage, sewerage, waterworks and utility works along
Man Kam To Road and Lin Ma Hang Road;
Ÿ
Associated geotechnical works including cut and fill slopes, soil nailing
works and retaining structures; and
Ÿ
Associated landscaping works.
1.1.4
CEDD
Contract No. (to be advised) (hereafter referred as “Contract 3”):-
Ÿ
Site Formation for the platform of the columbarium site;
Ÿ
Construction of two 2 at-grade access roads;
Ÿ
Construction of road junction between Man Kam To Road and the new
access road;
Ÿ
Associated drainage, sewerage and waterworks along the two new
access roads;
Ÿ
Associated geotechnical works including cut and fill slopes, soil
nailing works and retaining structures; and
Ÿ
Associated landscaping works
1.1.5
Hsin Chong Tsun
Yip Joint Venture (hereinafter “HCTYJV”) has been awarded the Works Contract 1 on 5 December 2017. According to the Contract requirement,
HCTYJV
shall take over
the responsibility for part of Environmental
Permit No. EP-534/2017 for ease of management, therefore application for Further Environmental Permit was submitted by HCTYJV to EPD on 26 January 2018 and Further Environmental Permit No. FEP-01/534/2017
was granted to
HCTYJV by EPD on
23 February 2018. Major works to be executed under the Project shall include to the
following:
A Designated Works under EP-534/2017
(i)
Site formation of about 8 hectares of
land and associated drainage, sewerage and landscape works for development of
Columbarium and Crematorium facilities at the Sandy Ridge Cemetery;
(ii)
Construction of a new road (about 600m)
including a section of viaduct connecting the platform for Crematorium and Man
Kam To Road and the pick-up/drop-off point at Man Kam To Road.;
(iii)
Widening of about 900m of the existing
Sha Ling Road;
(iv)
Widening of about 1.4km of the existing
Lin Ma Hang Road; and
(v)
Improvement works to the existing
barging point at Siu Lam
Non-Designated Works
(i)
Construction of a sewage detention tank
complete with odour and septicity control mechanism;
(ii)
Construction of noise barriers along Sha
Ling Road;
(iii)
Construction of a new Refuse Collection
Point (RCP) near the junction between Man Kam To Road and Sha Ling Road;
(iv)
Landscaping works (including both hard
and soft landscape works);
(v)
Associated tree felling, transplanting
and compensatory planting works;
(vi)
Associated street lighting, street
furniture and road marking, etc.; and
(vii) Other
works which are specified in PS of the Contract.
1.1.6
Action-United
Environmental Services & Consulting has been commissioned by HCTYJV as an
Environmental Team to implement the EM&A programme in accordance with the
approved EM&A Manual as well as the associated duties. As part of the
EM&A programme, baseline monitoring
to determine the ambient environmental conditions was completed before construction work commencement. The Baseline Monitoring Report (air, noise and water) certified
by Environmental Team Leader (ETL) and verified by Independent Environmental
Checker (IEC) was submitted to Environmental Protection Department (EPD) on 30
May 2018 and subsequently revised on 8 August 2018 upon comments from EPD.
Further comment was issued by EPD on 15 August 2018 and the Baseline Monitoring
Report (Version 3) was submitted to EPD on 13 September 2018 for endorsement.
1.1.7
This
is the 2nd
monthly Environmental Monitoring and Audit Report to reporting the
monitoring results and inspection findings for the period from 1 to 30 September 2018.
1.2.1
The Monthly
Environmental Monitoring and Audit (EM&A) Report is structured into the
following sections:-
Section 1 Introduction
Section 2 Project Organization and Construction Progress
Section 3 Summary of Monitoring Requirements
Section 4 Air Quality Monitoring Results
Section 5 Noise Monitoring Results
Section 6 Water Quality Monitoring Results
Section 7 Ecology Monitoring Results
Section 8 Landscape & Visual
Section 9 Waste Management
Section 10 Site Inspections
Section 11 Environmental Complaints and Non-Compliance
Section 12 Implementation Status of Mitigation Measures
Section 13 Conclusions and Recommendation
2
Organization and
Construction progress of the Works Contract-1
2.1.1
Organization
structure and contact details of relevant parties with respect to on-site
environmental management are shown in Appendix B.
2.1.2
The
three month rolling construction programme are enclosed in Appendix C
and the major construction activities undertaken in this Reporting Month are
listed below:-
l General site clearance;
l Bulk Excavation
l Construction of temporary Site Office;
l Construction of Cut Slope,
installation of soil nailing and construction of surface channel;
l Sheetpiling works for retaining wall; and
l Construction of retaining
wall.
2.3
Summary
of Environmental
Submissions
2.1.3
Summary of the relevant permits, licences, and/or notifications on environmental protection
for this Project in this Reporting Month is presented in Table 2-1.
Table
2-1 Status of Environmental Licenses and Permits
|
Item
|
Description
|
License/Permit Status
|
|
1
|
Air
Pollution Control (Construction Dust) Notification
|
Notified
EPD on 20 December 2017
|
|
2
|
Chemical
waste Producer Registration
(WPN:
5231-641-H3937-01)
|
Application
date: 28 December 2017
Date
issued: 27 March 2018
|
|
3
|
Water
Pollution Control Ordinance
(Discharge
License: WT00030795-2018)
|
Issued
date: 9/5/2018
Expire
Date: 31/5/2023
|
|
4
|
Billing
Account for Disposal of Construction Waste (Account Number: 7029769)
|
Application
no. : NA
Date
approved: NA
|
|
5
|
Construction Noise Permit
(GW-RN0490-18)
|
Issued
date: 14/9/2018
Expire
Date: 18/11/2018
|
2.4
Summary
of Submission Under the Environmental
Permit Requirements
2.1.4
Table 2-2
summarized the submission status under the EP and/or FEP stipulation in the
Reporting Month.
Table
2-2 Status of Submission as under EP and/or FEP Stipulation
|
Item
|
EP and / or FEP
Stipulation
|
Description
|
Situation
|
|
1
|
Condition 2.10 of the EP and FEP
|
Management organization of : i) the main
construction companies; ii) ET; and iii) IEC and the supporting team
|
Submitted on 11 April
2018
|
|
2
|
Condition 2.11 of the EP and FEP
|
i) Detailed phasing programme
of all construction works; and ii) Location plan of all construction works
|
Submitted on 12 April
2018
|
|
3
|
Condition 2.13 of
EP and Condition 2.12 of
FEP
|
Contamination
Assessment Plan (CAP)
|
Submitted to IEC on 18
September 2018 for verification
|
|
4
|
Condition 2.14 of EP and Condition 2.13 of FEP
|
Grassland Reinstatement Plan
|
Submitted on 28 May 2018
|
|
5
|
Condition 2.15 of EP and Condition 2.14 of FEP
|
Vegetation Survey
Report
|
Submitted on 21 May 2018
|
|
6
|
Condition 2.16 of EP and Condition 2.15 of FEP
|
Vegetation Transplantation Proposal
|
Submitted on 21 May 2018
|
|
7
|
Condition 2.18 of EP and Condition 2.17 of FEP
|
Woodland
Compensation Plan
|
Submitted on 15 May 2018
|
|
8
|
Condition 2.19 of EP and Condition 2.18 of FEP
|
Monitoring and
Survey Plan for Golden-headed Cisticola
|
Submitted on 9 May 2018
|
|
9
|
Condition 2.22 of EP and Condition 2.20 of FEP
|
Landscape
& Visual Mitigation and Tree Preservation Plan(s)
|
Submitted on 18 May 2018
|
|
10
|
Condition 2.24 of EP and Condition 2.22 of FEP
|
Traffic Noise
Mitigation Plan
|
Submitted on 17 July 2018
|
|
11
|
Condition 3.3 of the EP and FEP
|
Baseline Monitoring
Report (BMR)
|
BMR (version 1) submitted on 8 May 201;
BMR (version 2) submitted on 8 Aug 2018
BMR (version 3 submitted on 13 Sep 2018
|
|
12
|
Condition 4.2 of the EP and FEP
|
The Contract Internet website
|
Internet website address has notified EPD on 15 Jun 2018
|
3.1.1
The Environmental Monitoring and Audit requirements are set out in
the Approved EM&A Manual. Environmental issues such as air quality,
construction noise, water quality and ecology were identified as the key issues
during the construction phase of the Project.
3.1.2
A summary of construction phase EM&A
requirements are presented in the sub-sections below.
3.2.1
The EM&A impact monitoring shall cover the following
environmental aspect:
•
Air quality;
•
Construction noise;
•
Water quality; and
•
Ecology
3.2.2
A summary of the monitoring parameters is presented in Table
3-1 below
Table 3-1 Summary
of EM&A Requirements
|
Environmental
Issue
|
Parameters
|
|
Air Quality
|
Ÿ 1-hour TSP;
Ÿ 24-hour TSP
|
|
Noise
|
Ÿ Leq(30min) during normal working hours.; and
Ÿ
Leq(15min) during the construction works is undertaken in
Restricted Hours
|
|
Water Quality
|
In-situ
Measurements
Ÿ Dissolved Oxygen
Concentration (mg/L) & Saturation (% );
Ÿ Temperature (℃);
Ÿ Turbidity (NTU);
Ÿ Salinity
(ppm)
Ÿ pH unit;
Ÿ Water depth (m); and
Ÿ Stream Flow
Velocity (m/sec).
|
|
Laboratory Analysis
Ÿ Suspended Solids (mg/L)
|
|
Ecology
|
Ecologically sensitive habitats
(wetland habitats and non-wetland habitats)
|
3.3.1
According to
the Approved EM&A Manual of the Project - Site Formation and Associated Infrastructural Works for
Development of Columbarium, Crematorium and Related Facilities at Sandy Ridge
Cemetery, the designated monitoring
locations for air quality, noise, water quality and ecology under the monitoring programme, is shown in Appendix D.
3.3.2
Since the Project was divided
into three Works Contracts and all Contracts will be
commenced at different time, the
construction phase impact monitoring will only be performed at the
Contract-related monitoring stations upon commencement of each
Contract Works.
Air Quality
3.3.3
There were three (3) air
quality monitoring
stations / air quality sensitive receivers (ASR) recommended in the Approved EM&A Manual Section 5.6.1.1.
The designated air quality monitoring locations were listed in Table 3-2 and illustrated in Appendix D.
Table 3-2 Designated
Air Quality Monitoring Location under the Project
|
Location
ID
|
ASR ID in EIA
|
Description
|
Location
|
|
ASR-1
|
A1
|
Village House along Man Kam To Road
|
Sha Ling
Village House No.6
|
|
ASR-2
|
A2
|
Village
House at San Uk Ling
|
San Uk Ling Village House No.1
|
|
ASR-3
|
A3
|
Village House at Muk Wu Nga Yiu
|
Muk Wu Nga Yiu House No.28
|
3.3.4
Based on rationale in Section 3.3.2, the Contract-related air quality monitoring location under construction
phase of Contract 1 is shown in Table 3-3.
Table 3-3 Air Quality Monitoring Location
as Related the Works Contract-1
|
Location
ID
|
ASR ID in EIA
|
Description
|
Location
|
|
ASR-1
|
A1
|
Village House
along Man Kam To Road
|
Sha Ling Village
House No.6
|
3.3.5
If the designated monitoring
location is required to relocate, alternative monitoring location shall meet
the following
criteria:
i)
Be at the site
boundary or such locations close to the major dust emission source;
ii)
Close to the sensitive receptors;
iii)
Take into account the prevailing
meteorological conditions;
iv)
For monitoring location located in the
vicinity of the ASRs, care shall be taken to cause minimal disturbance to the
occupants during monitoring.
v)
When positioning the HVS, the following
points shall be
noted:
a.
a horizontal platform with appropriate
support to secure the samples against gusty wind shall be provided;
b.
no two samplers shall be placed less than 2m
apart;
c.
the distance between the HVS and an obstacle,
such as buildings, must be at least twice the height that the obstacle
protrudes above the HVS;
d.
a minimum of 2 m separation from walls, parapets and
penthouses is required for HVS at the rooftop;
e.
a minimum of 2 m separation from any supporting structure,
measures horizontally is required;
f.
no furnace or incinerator flue is nearby;
g.
airflow around the sampler is unrestricted;
h.
the HVS is more than 20 m from the dripline;
i.
any wire fence and gate to protect the HVS,
shall not cause any obstruction during monitoring;
j.
permission must be obtained to set up the HVS
and to obtain access to the monitoring stations; and
k.
a secured
supply of electricity is needed to operate the HVS.
3.3.6
Alternative monitoring location shall agree with IEC and seek for EPD approval.
Construction
Noise
3.3.7
There were are
four (4) noise monitoring locations / noise sensitive receivers (NSR)
recommended in the Approved EM&A Manual Section 6.5.1.1. Site visits were conducted by the Contractor
and ET on 6th & 10th April 2018 to review
and study sensitive
receivers at surrounding and adjacent to the Project. Four designated noise monitoring locations
recommended in the Approved EM&A Manual were identified during the
site visits. They were listed in Table 3-4 and shown in Appendix D.
Table 3-4 Designated
Construction Noise Monitoring Location under the Project
|
Location
ID
|
NSR ID in EIA
|
Description
|
Location
|
|
CN-1
|
N5-2
|
Village
house to the west of Sha Ling Road
|
Village house
to the west of Sha Ling Road (free field
condition)
|
|
CN-2
|
N9-1
|
Village house to
the north of Man Kam To Road
|
Sha Ling Village House No. 25 (free field condition)
|
|
CN-3
|
N18-5
|
Village house near
San Uk Ling
|
San Uk Ling Village House No. 18 (free field condition)
|
|
CN-4
|
N21-4
|
Village
house of Muk Wu
|
Muk Wu Village House No. 267 (1m façade from the building)
|
3.3.8
Based on rationale in Section 3.3.2, the Contract-related noise monitoring location under construction
phase of Contract 1 is listed in Table 3-5.
Table 3-5 Noise Monitoring Location as Related
the Works Contract-1
|
Location
ID
|
ASR ID in EIA
|
Description
|
Location
|
|
CN-1
|
N5-2
|
Village
house to the west of Sha Ling Road
|
Village house
to the west of Sha Ling Road (free field
condition)
|
|
CN-2
|
N9-1
|
Village house to
the north of Man Kam To Road
|
Sha Ling Village House No. 25 (free field condition)
|
Water Quality
3.3.9
There were four (4) water quality monitoring
locations recommended in the Approved EM&A
Manual Section 7.6.1.2. The locations and coordinates of water quality monitoring were listed in Table 3-6 and illustrated in Appendix D.
Table 3-6 Designated
Water Quality Monitoring Stations under the Project
|
Proposed Location ID
|
Co-ordinates
|
Description
|
|
North
|
East
|
|
M1
|
843 431
|
831 308
|
Midstream
of Nam Hang Stream
|
|
M2
|
843 840
|
831 101
|
Downstream
of Nam Hang Stream
|
|
M3
|
843 509
|
830 040
|
Wetland
in the Conservation Area (CA) near Yuen Leng Chai
|
|
M4
|
843 997
|
831 783
|
Watercourse across Lin Ma
Hang Road, running from east of San Uk Ling to Man
Kam To Boundary Control Point
|
3.3.10 Based on
rationale in
Section 3.3.2, the
Contract-related water
quality monitoring station under construction phase of Contract 1 is listed in Table 3-7.
Table 3-7 Water
Quality Monitoring Station as Related the Works Contract-1
|
Proposed Location ID
|
Co-ordinates
|
Description
|
|
North
|
East
|
|
M3
|
843 509
|
830 040
|
Wetland
in the Conservation Area (CA) near Yuen Leng Chai
|
3.4.1
The requirements of impact monitoring were stipulated in Sections 5.8.1.1, 6.7.1.1 and
7.8.1.4 of the approved EM&A
Manual and presented as follows.
Air Quality
Monitoring
3.4.2
Monitoring frequency for air quality impact monitoring is as follows:
|
Ÿ 1-Hour TSP
|
3 sets of 1-hour TSP monitoring shall be
carried out once every six days during construction periods
|
|
Ÿ 24-Hour TSP
|
Once 24-hour TSP monitoring shall be
carried out every six days during construction periods
|
Noise Monitoring
3.4.3
Noise impact monitoring shall be carried out once per week during
construction periods. The noise
measurement for the time period between 0700 and 1900 hours shall be measured
in terms of Leq (30 minutes) or 6 sets
of Leq (5mins).
Water Quality Monitoring
3.4.4
The monitoring frequency shall be 3 days per week during
construction phase and the interval between two sets of monitoring shall not be less
than 36 hours.
3.5.1
The
monitoring equipment using for the EM&A program as proposed by the ET shall
be verified by the IEC.
Air Quality
Monitoring
3.5.2
The 24-hour and 1-hour TSP levels shall be measured by following
the standard high volume sampling method as set out in the Title 40 of the Code of Federal Regulations, Chapter 1 (Part 50), Appendix B. If ET proposes to use a direct reading
dust meter to measure 1-hour TSP levels, it shall submit sufficient information
to IEC for approval.
3.5.3
The filter paper
of 24-hour TSP measurement shall be determined by HOKLAS accredited laboratory.
3.5.4
All equipment used by ET for air quality monitoring is listed in Table
3-8.
Table 3-8 Air
Quality Monitoring Equipment
|
Equipment
|
Model
|
|
24-Hr TSP
|
|
High Volume Air
Sampler (HVAS)
|
TISCH High Volume Air Sampler, HVS Model
TE-5170
|
|
Calibration
Kit
|
TISCH Model TE-5025A
|
|
1-Hour TSP
|
|
Portable Dust Meter
|
Sibata LD-3 Laser Dust monitor
Particle Mass Profiler & Counter
|
Wind Data Monitoring Equipment
3.5.5
According to the approved EM&A Manual, wind data monitoring
equipment shall also be provided and set up for logging wind speed and wind
direction near the dust monitoring locations. The equipment installation location
shall be proposed by the ET and agreed with the IEC. For installation and operation of wind
data monitoring equipment, the following points shall be observed:
1)
The wind sensors should be installed 10 m above ground so that
they are clear of obstructions or turbulence caused by buildings.
2)
The wind data should be captured by a data logger. The data shall
be downloaded for analysis at least once a month.
3)
The wind data monitoring equipment should be re-calibrated at least
once every six months.
4)
Wind direction should be divided into 16 sectors of 22.5 degrees
each.
3.5.6
ET has liaised with the premises owners/ landlords to grant the permission
for the HVS installation. However, they rejected to set
up wind data
monitoring equipment installation in their premises.
3.5.7
Under this situation, the ET proposed to obtain representative
wind data from the Hong Kong Observatory Ta Kwu Ling Weather Station. Ta Kwu Ling Station is located near the Project site which situated at the sea level above 15mPD and
the wind data
monitoring equipment is installed 10 m above the existing ground.
Noise Monitoring
3.5.8
Sound level meter in compliance with the International Electrotechnical Commission Publications 651: 1979 (Type 1)
and 804: 1985 (Type 1) specifications shall be used for carrying out the noise
monitoring. The sound level meter
shall be checked using an acoustic calibrator. The wind speed shall be checked with a
portable wind speed meter capable of measuring the wind speed in ms-1
before each noise monitoring event.
Noise measurements should not be made in fog, rain, wind with a steady speed
exceeding 5 m s-1 or wind with gusts exceeding 10 m s-1.
3.5.9
Noise monitoring equipment used for impact monitoring is listed in
Table
3-9.
Table 3-9 Noise
Monitoring Equipment
|
Equipment
|
Model
|
|
Integrating Sound Level Meter
|
B&K
Type 2238
|
|
Calibrator
|
B&K
Type 4231
|
|
Portable Wind Speed Indicator
|
Testo Anemometer
|
3.5.10 Sound level meters listed above
comply with the International Electrotechnical Commission Publications 651: 1979 (Type 1)
and 804: 1985 (Type 1)
specifications, as recommended in TM issued under the NCO.
Water Quality
Monitoring
3.5.11 Water
quality parameters include dissolved oxygen, water
temperature & depth, turbidity, salinity, pH and stream flow velocity shall
be measured in-situ, and suspended solids shall be analyzed by a HOKLAS-accredited
testing laboratory.
Dissolved Oxygen and Temperature Measurement
3.5.12 The dissolved oxygen (DO) measuring
instruments should be portable and weatherproof. The equipment should also
complete with cable and sensor, and DC power source. It should be capable of
measuring:
• A DO level
in the range of 0 – 20 mg/L and 0 – 200% saturation; and
• A temperature of 0 – 45 degree Celsius.
3.5.13
The
equipment should have a membrane electrode with automatic temperature
compensation complete with a cable.
3.5.14
Should
salinity compensation not be built-in to the DO equipment, in-situ salinity
should be measured to calibrate the DO measuring instruments prior to each
measurement.
Turbidity Measurement
3.5.15
The turbidity measuring instruments should be
a portable and weatherproof with DC power source. It should have a photoelectric sensor
capable of measuring turbidity level between 0–1000 NTU (for example, Hach model 2100Q or an
approved similar instrument).
Salinity Measurement
3.5.16
A portable salinometer
capable of measuring salinity in the range of 0–40 parts per thousand (ppt) should be provided for measuring salinity of the water
at each monitoring location.
pH Measurement
3.5.17
A portable pH meter capable of measuring a
range between 0.0 and 14.0 should be provided to measure pH under the specified
conditions accordingly to the APHA Standard Methods.
Water Depth Measurement
3.5.18
A portable, battery-operated echo sounder or
an approved similar instrument should be used for water depths determination at
each designated monitoring station.
Stream Flow Velocity Equipment
3.5.19
Since the EM&A Manuals do not specified instrument to use
stream flow velocity measurement, the monitoring of stream flow velocity is
therefore proposed to be conducted by using a flow probe which is a digital
water velocity meter.
Water Sampling Equipment
3.5.20
A water sampler is required for suspended
solid (SS) monitoring. A water sampler e.g. Kahlsico Water Sampler, which is a transparent PVC cylinder
with capacity not less than 2 litres, will be used
for water sampling if water depth over than 0.5m.
3.5.21
For sampling from very shallow water depths e.g. <0.5 m, water
sample will be collected from water surface below 100mm using plastic bottle to avoid
inclusion of bottom sediment or humus.
Moreover, Teflon/stainless steel bailer or self-made sampling buckets
maybe used for water sampling. The
equipment used for sampling will be depended the sampling location and depth
situations.
Sample Containers and Storage
3.5.22
Water samples for suspended solid should be
stored in high density polythene bottles with no preservative added, packed in ice
(cooled to 4°C without being frozen) and delivered to the laboratory within 24
hours of collection and be analyzed as soon as possible after collection.
3.5.23 Analysis of suspended solids should
be carried out in a HOKLAS or other accredited laboratory. Water samples of
about 1L should be collected at the monitoring stations for carrying out the
laboratory suspended solids determination.
The SS determination work should start within 24 hours after collection
of the water samples. The SS analyses should follow the APHA Standard Methods 2540D with Limit of Reporting of 2 mg/L.
3.5.24 Details of the equipment used for water
quality monitoring are listed in Table 3-10
below.
Table 3-10 Water
Quality Monitoring Equipment
|
Equipment
|
Model
|
|
Water Depth Detector
|
Tape measures
|
|
Water Sampler
|
A
2-litre transparent PVC cylinder with latex cups at both ends or teflon/stainless steel bailer or self-made sampling
bucket
|
|
Thermometer & DO meter
|
YSI 550A / YSI Pro 20
|
|
pH meter
|
AZ8685 pH meter
|
|
Turbidimeter
|
Hach 2100Q
|
|
Salinometer
|
Atago refractometer Atago S Salinity Meter /
AZ8371 Salinity Meter
|
|
Stream Flow Velocity
|
FP211 Global Flow Probe
|
|
Sample Container
|
High density polythene
bottles (provided by laboratory)
|
|
Storage Container
|
‘Willow’ 33-litter plastic
cool box with Ice pad
|
3.5.25 Furthermore, Suspended solids (SS) analysis was carried out by ALS Technichem
(HK) Pty Ltd, he is one a local HOKLAS-accredited laboratory
3.6.1
The HVAS is operated and calibrated on a regular basis in
accordance with the manufacturer’s instruction using Tisch Calibration Kit Model
TE-5025A. Calibration would carry
out in two month interval.
The calibration data are properly documented and the records are
maintained by ET for future reference.
Furthermore, Tisch Calibration Kit will be calibrated by the
manufacturer in yearly basis.
3.6.2
The 1-hour TSP meter calibrated by a local HOKLAS-accredited
laboratory would be undertaken in yearly basis. Zero response of the equipment was
checked before and after each monitoring event.
3.6.3
The sound level meter and acoustic calibrator are
calibrated and certified by a laboratory accredited under HOKLAS or any other
international accreditation scheme at yearly basis.
3.6.4
The multi-parameter Water Quality Monitoring
System is calibrated by HOKLAS accredited laboratory of three month intervals.
3.6.5
All updated calibration certificates of the
monitoring equipment used for the impact monitoring program in this Reporting
Month are attached in Appendix E.
3.7.1
The
impact monitoring data are handled by the ET’s systematic data recording and
management, which complies with in-house Quality Management System. Standard
Field Data Sheets (FDS) are used in the impact monitoring program.
3.7.2
The
monitoring data recorded in the equipment e.g. 1-hour TSP meter, noise meter
and Multi-parameter Water
Quality Monitoring System are downloaded
directly from the equipment at the end of each monitoring day. The downloaded monitoring data are input
into a computerized database properly maintained by the ET. The laboratory results are input
directly into the computerized database and QA/QC checked by personnel other
than those who input the data. For
monitoring activities require laboratory analysis, the local laboratory follows
the QA/QC requirements as set out under the HOKLAS scheme for all laboratory
testing.
3.8.1
The baseline monitoring results form the basis for
determining the environmental acceptance criteria for the impact monitoring. the
air quality, construction noise and water quality criteria, namely Action and Limit levels were established according to Approved EM&A Manual, and they are
listed in Tables 3-11, 3-12 and 3-13 below.
Table 3-11 Action and Limit Levels for Air
Quality Monitoring
|
Monitoring
Stations
|
Action
Level (mg/m3)
|
Limit
Level (mg/m3)
|
|
1-hour
|
24-hour
|
1-hour
|
24-hour
|
|
ASR-1
|
331
|
181
|
500
|
260
|
Table 3-12 Action
and Limit Levels for Construction Noise
|
Time
Period
|
Action
Level
|
Limit
Level
|
|
0700-1900 hours on normal
weekdays
|
When one documented complaint is received
|
> 75* dB(A)
|
Note: * Reduces to 70 dB(A)
for schools and 65 dB(A) during the school examination periods.
Table 3-13 Action
and Limit Levels for Water Quality
|
Monitoring Location
|
DO (mg/L)
|
Turbidity (NTU)
|
SS (mg/L)
|
|
Action Level
|
Limit Level
|
Action Level
|
Limit Level
|
Action Level
|
Limit Level
|
|
M3
|
4.58
|
4.49
|
5.6
|
5.9
|
9.3
|
9.5
|
|
Notes:
•
For DO, non-compliance of the water
quality limits occurs when monitoring result is lower than the limits
•
For turbidity and SS, non-compliance of
the water quality limits occurs when monitoring result is higher than the
limits.
|
3.8.2
Should
non-compliance of the environmental quality criteria occurs, remedial actions will
be triggered according to the Event and Action Plan enclosed in Appendix F.
4.1.1
Air quality impact monitoring schedule was submitted to
relevant party on 24 August 2018 and shown in Appendix G.
4.1.2
In
this Reporting
Period, 5
occasions 24-hour TSP and 15 occasions 1-hour TSP of the air quality monitoring was undertaken
at designated
air quality monitoring location ASR-1. The monitoring results for 24-hour and 1-hour TSP are
summarized in Table 4-1. The database of 24-hour TSP is shown in Appendix H and the graphical plots of 24-hour and 1-hour
TSP result
are shown in Appendix I.
Table
4-1 Summary
of 24-hour and 1-hour TSP Monitoring Results at ASR-1
|
Date
|
24-hour
TSP (mg/m3)
|
1-hour
TSP (mg/m3)
|
|
Date
|
Start Time
|
1st hour
measured
|
2nd hour
measured
|
3rd hour
measured
|
|
3-Sep-18
|
25
|
4-Sep-18
|
9:41
|
38
|
41
|
45
|
|
8-Sep-18
|
68
|
10-Sep-18
|
9:46
|
53
|
57
|
63
|
|
14-Sep-18
|
76
|
15-Sep-18
|
9:30
|
47
|
53
|
50
|
|
20-Sep-18
|
102
|
21-Sep-18
|
9:36
|
51
|
62
|
66
|
|
26-Sep-18
|
67
|
27-Sep-18
|
12:54
|
105
|
110
|
114
|
|
Average
(Range)
|
68
(25 - 102)
|
Average
(Range)
|
64
(38 – 114)
|
4.1.3
The
meteorological data during the impact monitoring days are summarized in Appendix J.
4.2.1
As
shown in Table 4-1, the monitoring results of 24-hour and 1-hour TSP monitoring in the Reporting Month were well below the Action Level. No Notification of Exceedance (NOE) of air quality monitoring criteria was issued and therefore corrective action was not required.
5.1.1
Noise impact monitoring schedule was submitted to
relevant party on 24 August 2018 and shown in Appendix G.
5.1.2
In
this Reporting
Month, 4
occasions of noise monitoring were undertaken at designated noise monitoring
location CN-1. The sound level were set in a free field situation, and therefore a façade correction of +3dB(A)
has been added according to acoustical principles and EPD guidelines. Since the distance of current construction works of Contract 1 over 300m from CN-2,
noise monitoring was not performed at that
location in this Reporting Month. The monitoring result of noise monitoring is show in Table 5-1 and the
graphical plots are shown in Appendix I.
Table
5-1 Summary
of Construction Noise Monitoring
Results, dB(A) – CN1
|
Date
|
Start
Time
|
1st
Leq5min
|
2nd
Leq5min
|
3rd
Leq5min
|
4th
Leq5min
|
5th
Leq5min
|
6th
Leq5min
|
Leq30min
|
Corrected* Leq30min
|
|
4-Sep-18
|
9:49
|
57.6
|
56.3
|
56.0
|
54.5
|
58.3
|
56.8
|
57
|
60
|
|
10-Sep-18
|
9:40
|
71.8
|
62.3
|
61.2
|
64.3
|
60.5
|
62.1
|
66
|
69
|
|
21-Sep-18
|
9:32
|
63.4
|
62.8
|
61.7
|
61.8
|
59.3
|
58.2
|
62
|
65
|
|
27-Sep-18
|
13:03
|
58.3
|
57.0
|
58.2
|
53.4
|
56.5
|
55.3
|
57
|
60
|
|
Limit Level
|
-
|
75
|
(*) A façade correction of +3dB(A) has
been added according to acoustical principles and EPD guidelines.
5.1.3
Prior and after noise monitoring, the accuracy of the sound level meter
has been checked by
an acoustic calibrator to
ensure the measurement within acceptance range of ±0.5dB. Moreover, wind speed checked
by portable wind speed meter has
been performed before noise monitoring. No
noise measurement was performed in fog, rain, wind with a steady speed
exceeding 5 m s-1 or wind with gusts exceeding 10 m s-1.
5.2.1
As
shown in Table 5-1, no noise monitoring results exceeded the Limit Level in the Reporting Month. No Notification of Exceedance (NOE) of
construction noise criterion was issued and no corrective action was therefore required.
6
Water Quality
6.1.1
Water quality impact monitoring schedule was submitted to relevant
party
on 30
July 2018 and shown in
Appendix G.
6.1.2
In the Reporting
Month, impact water quality monitoring at M3 on 18 September 2018 was cancelled
since the access road was blocked by fallen trees after the attack by Super
Typhoon Mangkhut. Therefore, a
total of 12 monitoring
days were carried
out at designated monitoring station M3 for water quality impact monitoring.
The monitoring result of key parameters including Dissolved
Oxygen, Turbidity and
Suspended Solids are summarized in Table 6-1. Detailed monitoring results including
in-situ measurements and laboratory analysis data are shown in Appendix H and graphical
plots for monitoring
result are shown in Appendix I.
Table
6-1 Summary
of Water Quality Monitoring Results – M3
|
Date
|
Parameters
|
|
DO (Averaged)
(mg/L)
|
Turbidity (Averaged)
(NTU)
|
Suspended
Solids
(Averaged)
(mg/L)
|
|
1-Sep-18
|
6.47
|
75.5
|
22.5
|
|
3-Sep-18
|
6.19
|
75.7
|
25.0
|
|
5-Sep-18
|
4.90
|
47.2
|
15.5
|
|
7-Sep-18
|
5.87
|
33.3
|
12.0
|
|
11-Sep-18
|
5.52
|
28.6
|
11.5
|
|
13-Sep-18
|
6.32
|
27.6
|
10.0
|
|
15-Sep-18
|
6.13
|
15.5
|
7.0
|
|
20-Sep-18
|
6.38
|
18.1
|
7.0
|
|
22-Sep-18
|
5.48
|
16.6
|
7.0
|
|
24-Sep-18
|
9.61
|
9.2
|
4.5
|
|
27-Sep-18
|
5.71
|
7.2
|
5.5
|
|
29-Sep-18
|
5.91
|
7.1
|
5.5
|
Remarks:
bold and underline
indicated Limit Level exceedance
6.1.3
During the Reporting Month, field measurements at M3 showed that temperature of stream water
were within 26.6°C to 30.7°C, the salinity concentrations below 0.1ppt, pH values within 6.5
to 8.5 and the stream flow velocity
between
0.1 and 0.2 m/sec.
6.2.1
In this Reporting Period, a total of eighteen (18) Limit Level exceedances, including twelve (12) Limit
Level exceedances of turbidity and six (6)
Limit Level exceedances of Suspended Solids were recorded at
M3 they are summarized in Table 6-2.
Table
6-2 Action and Limit (A/L) Levels Exceedance
Record
|
Station
|
DO
|
Turbidity
|
SS
|
Total Exceedance
|
Project
Related exceedance
|
|
Action
|
Limit
|
Action
|
Limit
|
Action
|
Limit
|
Action
|
Limit
|
Action
|
Limit
|
|
M3
|
0
|
0
|
0
|
12
|
0
|
6
|
0
|
18
|
0
|
0
|
6.2.2
Investigation
for the cause of water quality exceedances have been undertaken by ET. Investigation results revealed that water quality
mitigation measures have been implemented to minimize the water quality impact
arising from contract works. Such as temporary bund and de-silting trench were installed
at Retaining Wall RW1 to reduce the suspended solids content in runoff. Series of sheet pile was installed at
site boundary to prevent site runoff flowing to the Conservation Area (CA). Moreover,
exposed surface were covered by tarpaulin sheet as far as practicable. It was observed that
construction of temporary drainage system was on-going and no muddy discharge was observed. Since there
were continuous rainstorms which affecting the water quality of seasonal river course and the pond
of M3 is a catchment of rainwater, it is concluded that the exceedances were related to the impact of rain and unlikely
caused by the works under the Contract 1.
6.2.3
Notifications of Exceedance (NOE) were issued to relevant parties upon confirmation of the monitoring
result. The exceedance
investigation findings are summarized in Table 6-3.
Table 6-3 Summary
of Investigation Finding of Water Quality Exceedance in the Reporting Period
|
Date of Exceedance
|
Exceeded Parameter
|
Cause of Water Quality Exceedance In
Brief
|
|
1, 3, 5,
7,11 and 13 September 2018
|
NTU & SS
|
HCTYJV had implemented water quality mitigation
measures and there was no adverse water
quality impact observed during the site inspection.
Having
reviewed the baseline monitoring data at M3, Suspended
Solids of 23.5mg/L was recorded during rainy condition, therefore, the
impact monitoring results of SS are similar to baseline during rainy
condition. It is concluded that the exceedances were related
to the impact of rainstorm and unlikely caused by the
works under the Project.
|
|
15, 20,
22, 24, 27 and 29 September 2018
|
NTU
|
HCTYJV had implemented water quality mitigation
measures and there was no adverse water
quality impact observed during the site
inspection. Having reviewed the
monitoring data, it is noted that the level of turbidity was gradually
decreased to baseline level after rainstorm happened in early September
2018. Moreover, there was no
exceedance of Suspended Solids (SS).
It is concluded that the exceedances were related
to the impact of rainstorm and unlikely caused by the
works under the Project.
|
6.2.4
Although the exceedances were concluded as not related the works under Contract 1, the
Contractor was reminded to fully implement water quality mitigation measures such as
exposed surface and area with low operation frequency should be covered by
impervious sheeting. Moreover,
temporary drainage and collection system for site runoff should be fully
accomplished as soon as possible which could highly reduce water quality impact to
the surrounding watercourse and ecosystem.
7.1.1
According
to approved EIA report (AEIAR-198/2016), habitat types within project boundary
comprise of watercourse, grassland, upland grassland, plantation, woodland and
developed area. Natural habitats were of moderate ecological value in terms of
species diversity, species rarity, species abundance, ecological linkage as
well as nursery. Moreover, 0.3ha of wet woodland on the northern side of Sandy
Ridge was deemed habitat with high ecological value. Four types of habitats were regarded as
ecologically sensitive habitats, namely wet woodland, watercourses, upland
grassland and woodland. Considering human disturbance in upcoming construction
and operation phases, ecologically sensitive habitats shall be monitored in
accordance with EM&A Manual.
7.1.2
The objective of ecologically
sensitive habitats monitoring is to evaluate the effectiveness of measures to
minimize impacts on concerned habitats from disturbance and pollution. In order
to monitor the effectiveness of the measures to the minimize impact on
ecologically sensitive habitats from disturbance and pollution, monthly
monitoring during construction and operation phases is required as specified in
EM&A Manual. Standard faunal transect and sampling surveys cover both
wetland habitats
(wet woodland and watercourse) and
non-wetland habitats (upland grassland and woodland).
7.2.1
Wetland
habitats include wet woodland and watercourses. Monitoring surveys using
standardized quantitative methodology will conduct at fixed points. For seasonal watercourse, the survey
will be conducted whenever the habitat appears. Measures to respond to
decreases in numbers of aquatic fauna using the wetland habitats and
Action/Limit levels to trigger these measures are detailed in Table
7-1.
Table 7-1 Action and Limit Levels for Wet Woodland Habitats
Monitoring
|
Action
Level
|
Response
|
Limit
Level
|
Response
|
|
Reduction
in taxa diversity by 30%
|
Investigate
cause and if cause identified as related to the project instigate remedial action
to remove or reduce source of disturbance.
|
Reduction
in taxa diversity by 50%
|
Investigate
cause and if cause identified as related to the project instigate remedial
action.
|
Remarks:
Action and Limit Levels and Responses to Evidence of Declines in Aquatic Fauna
7.2.2
Non-wetland
habitats consist of upland grassland and woodland. Monthly quantitative surveys
of non-aquatic fauna will be conducted using standard route transect
counts. Measures to respond to
decreases in numbers of non-aquatic fauna using the non-wetland habitats and
Action/Limit levels to trigger these measures are detailed in Table
7-2.
Table 7-2 Action and Limit Levels for Non-Wet Woodland
Habitats Monitoring
|
Action
Level
|
Response
|
Limit
Level
|
Response
|
|
Reduction
in species diversity by 30%
|
Investigate
cause and if cause identified as related to the project instigate remedial
action to remove or reduce source of disturbance.
|
Reduction
in species diversity by 50%
|
Investigate
cause and if cause identified as related to the project instigate remedial
action.
|
Remarks:
Action and Limit Levels and Responses to Evidence of Declines in Non-Aquatic
Fauna
7.2.3
The
ecological survey includes all taxa being investigated in accordance with EIA
report. Schedule of faunal surveys in
each year during construction phase is presented in Table 7-3.
Table 7-3 Schedule of Faunal Surveys in each year During Construction
Phase
|
Month
|
Jan
|
Feb
|
Mar
|
Apr
|
May
|
Jun
|
Jul
|
Aug
|
Sep
|
Oct
|
Nov
|
Dec
|
|
Mammals
|
Ö
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
|
Birds (day)
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
|
Birds (night)
|
|
|
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
|
|
|
Herpetofauna
|
|
|
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
|
|
|
Dragonflies
|
|
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
|
|
|
Butterflies
|
|
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
|
|
|
Aquatic fauna
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
√
|
Mammal
Survey
7.2.4
Mammal surveys will be conducted along the proposed transects
(shown in Appendix D of the survey report) during both daytime and night time
periods. Along with direct observations, other field signs, such as scats and
tracks, will be searched and recorded if present.
Bird
Survey
7.2.5
Bird surveys will be conducted along the transects
(shown in Appendix D of the survey report) during the surveys, species and their vocalizing individuals
recorded will be enumerated and recorded according to the habitat(s) they are
utilizing.
Herpetofauna Survey
7.2.6
Reptile and amphibian surveys will be conducted along transects
(shown in Appendix D of the survey report) during surveys careful searches of
appropriate microhabitats and refugia for reptiles
and their vocalizing individuals will be undertaken and all reptiles observed
will be identified and counted.
Dragonfly
and Butterfly Survey
7.2.7
Dragonfly and Butterfly surveys will be conducted along transects
(shown in Appendix D of the survey report) during surveys all dragonflies and
Butterflies seen will be identified and counted as accurately as possible.
Aquatic
Fauna Survey
7.2.8
Freshwater fishes and macro-invertebrates will be recorded by
direct observation. All species trapped/recorded will be enumerated and
identified (to the lowest taxonomic level possible), and the species of conservation
importance photographed.
7.2.9
After
each ecological monitoring survey, a monthly report of the survey result and
data collected will be provided with reference to EM&A Manual. An annual
analysis of data will be carried out in order to study if there is any
significant reduction in taxa diversity and abundance.
7.3.1
In the Reporting Month,
ecological monitoring was undertaken on 11th September 2018. The weather of monitoring day was
fine. The monitoring survey was
included day and night sections, covering wetland and non-wetland areas. The survey was conducted by transect and
fixed points. All species seen will
be identified and counted as accurately as possible. Results of the monitoring survey are
presented below:
Mammal
7.3.2
An unknown bat was found in the project site.
Birds
7.3.3
There were a total
of 19 bird individuals from 13 species recorded during the survey. The species
of conservation interests were recorded in the monitoring area: Garrulax canorus,
Chinese Hwamei(畫眉)
Herpetofauna
7.3.4
There were no reptile recorded in the monitoring area. There was
one amphibian Fejervarya limnocharis,
Paddy Frog(澤蛙) found in the
monitoring area.
Dragonfly
7.3.5
There were a total
of 22 odonate individuals from 3 species, a species of
conservation interests, Urothemis signata,
Scarlet Basker (赤斑曲鈎脈蜻) was found in
upland glassland.
Butterfly
7.3.6
There were a total
of 12 butterfly individuals from 11 species recorded.
Aquatic Fauna Survey (Freshwater
communities)
7.3.7
A crab of conservation
importance Somanniathelphusa zanklon (鐮刀束腰蟹) was found in
marsh.
7.3.1
The summaries
of faunal survey result are shown in Tables 7-4, 7-5, 7-6, 7-8 and 7-9.
Table 7-4 Result
of Avifauna Survey
|
Scientific
Name
|
English
Name
|
Chinese
Name
|
Conservation
Status
|
Non-
wetland
|
Wetland
|
|
Ardea alba
|
Great Egret
|
大白鷺
|
Fellowes et al. (2002): PRC,(RC)
|
|
1
|
|
Amaurornis phoenicurus
|
White-breasted
Waterhen
|
白胸苦惡鳥
|
|
|
1
|
|
Eudynamys scolopaceus
|
Asian Koel
|
噪鵑
|
|
1
|
|
|
Lanius schach
|
Long-tailed
Shrike
|
棕背伯勞
|
|
1
|
1
|
|
Parus cinereus
|
Cinereous Tit
|
蒼背山雀
|
|
|
1
|
|
Pycnonotus jocosus
|
Red-whiskered
Bulbul
|
紅耳鵯
|
|
2
|
|
|
Pycnonotus sinensis
|
Chinese Bulbul
|
白頭鵯
|
|
2
|
|
|
Pycnonotus aurigaster
|
Sooty-headed
Bulbul
|
白喉紅臀鵯
|
|
|
3
|
|
Prinia flaviventris
|
Yellow-bellied
Prinia
|
黃腹鷦鶯
|
|
1
|
|
|
Orthotomus sutorius
|
Common
Tailorbird
|
長尾縫葉鶯
|
|
|
1
|
|
Garrulax canorus
|
Chinese Hwamei
|
畫眉
|
|
|
1
|
|
Garrulax chinensis
|
Black-throated
Laughingthrush
|
黑喉噪鶥
|
|
|
1
|
|
Gracupica nigricollis
|
Black-collared
Starling
|
黑領椋鳥
|
Appendix 2 of CITES
|
1
|
|
|
Motacilla alba
|
White Wagtail
|
白鶺鴒
|
|
|
1
|
Table 7-5 Result
of Reptile Survey
|
Scientific
Name
|
English
Name
|
Chinese
Name
|
Non-wetland
|
Wetland
|
|
--
|
--
|
--
|
--
|
--
|
Table 7-6 Result
of Amphibian Survey
|
Scientific
Name
|
English
Name
|
Chinese
Name
|
Conservation
Status
|
Non-
wetland
|
Wetland
|
|
Fejervarya limnocharis
|
Paddy Frog
|
澤蛙
|
|
|
1
|
Table 7-7 Result
of Butterfly Survey
|
Scientific
Name
|
English
Name
|
Chinese
Name
|
Non-
wetland
|
Wetland
|
|
Matapa aria
|
Common Redeye
|
瑪弄蝶
|
|
1
|
|
Parnara ganga
|
Rare Swift
|
曲紋稻弄蝶
|
|
1
|
|
Catochrysops strabo
Strabo
|
Forget-me-not
|
咖灰蝶
|
|
1
|
|
Everes lacturnus
|
Tailed Cupid,
Small Blue
|
長尾藍灰蝶
|
|
1
|
|
Zizina Otis
|
Lesser Grass
Blue
|
毛眼灰蝶
|
1
|
|
|
Abisara echerius
|
Plum Judy
|
蛇目褐蜆蝶
|
|
1
|
|
Cupha erymanthis
|
Rustic
|
黃襟蛺蝶
|
|
1
|
|
Discophora sondaica
|
Common Duffer
|
鳳眼方環蝶
|
|
1
|
|
Hestina assimilis
|
Red Ring Skirt
|
黑脈蛺蝶
|
2
|
|
|
Ypthima baldus
|
Common
Five-ring
|
矍眼蝶
|
1
|
|
|
Papilio polytes
|
Common Mormon
|
玉帶鳳蝶
|
1
|
|
Table 7-8 Result
of Odonate Survey
|
Scientific
Name
|
English
Name
|
Chinese
Name
|
Conservation
Status
|
Non-
wetland
|
Wetland
|
|
Orthetrum sabina sabina
|
Green Skimmer
|
狹腹灰蜻
|
|
|
1
|
|
Pantala flavescens
|
Wandering
Glider
|
黃蜻
|
|
20
|
|
|
Urothemis signata signata
|
Scarlet Basker
|
赤斑曲鈎脈蜻
|
Fellowes et al. (2002): LC
|
1
|
|
Table 7-9 Result
of Freshwater Communities Survey
|
Scientific
Name
|
English
Name
|
Chinese
Name
|
Conservation
Status
|
|
|
|
Somanniathelphusa zanklon
|
|
鐮刀束腰蟹
|
Fellowes et al. (2002): GC
|
20
|
|
7.3.2
The
detailed survey report is attached in Appendix K.
7.3.3
The tentative ecology inspection and monitoring in the next
reporting period (October 2018) is scheduled on 4th October 2018.
8.1.1
The EIA has recommended EM&A for landscape and visual
resources to be undertaken during the design, construction and operational
stages of the project. The design, implementation and maintenance of landscape
mitigation measures is a key aspect of this and should be checked to ensure
that they are fully realized and that potential conflicts between the proposed
landscape measures and any other project works let its are resolved at the
earliest possible date and without compromise to the intention of the
mitigation measures. In addition, implementation of the mitigation measures
recommended by the EIA will be monitored through the site audit programme.
8.1.2
A number of mitigation measures to ameliorate the landscape and
visual impacts of the Project implementation is
summarized in the EMIS of Appendix 13.1 of the EIA Report.
8.1.3
The landscape and visual
mitigation measures proposed should be incorporated in the landscape and
engineering design. Mitigation
measures to be implemented during construction should be adopted from the start
of construction and be in place throughout the entire construction period. Mitigation measures to be implemented
during operation should be integrated into the detailed design and built as
part of the construction works so that they are in place on commissioning of
the Project. Tree transplantation
and compensatory planting should be carried out as early as possible in the
Project with transplantation carried
out prior to construction starting in any particular area.
8.1.4
During
construction phase, Landscape & Visual Monitoring of the contractor’s operations should be conducted monthly and
reported by ET, and countersigned by IEC.
8.2.1
In the Reporting Period, landscape & Visual inspection was
carried out by the Registered Landscape Architect (RLA) on 28 September 2018. The findings / deficiencies observed during the inspection
are presented below:
|
Date
|
Findings / Deficiencies
|
|
28 September 2018
|
Observation:
1.
Typhoon Mangkhut lead to fallen trees
on site.
|
|
Reminder:
1. Construction works were being started.
According to ‘Tree Preservation’ No7/2015, 26a, Contractor was reminded to
provide TPZ with proper and robust fence at the dripline of all retained
trees. No works were allowed to undertake within the TPZ.
2. Typhoon Mangkhut lead to fallen trees on site,
contractor was reminded to remove these risk trees.
|
8.2.2
Inspection checklist of Landscape & Visual signed by RLA is attached in Appendix L.
9.1.1
Waste management was carried out by an on-site Environmental
Officer or an Environmental Supervisor from time to time in accordance with the
Waste Management Plan (WMP).
9.2.1
All types
of waste arising from the construction work are classified into the following:
l Construction & Demolition (C&D)
Material;
l Chemical Waste;
l General Refuse; and
l Excavated Soil.
9.2.2
The
quantities of waste for disposal in this Reporting Period are summarized in Table 9-1 and 9-2 and
the Monthly Summary Waste Flow Table is shown in
Appendix M. Whenever possible, materials were reused
on-site as far as practicable.
Table
9-1 Summary of Quantities of Inert C&D
Materials
|
Type of Waste
|
Quantity
|
Disposal Location
|
|
C&D
Materials (Inert) (m3)
|
0
|
-
|
|
Reused
in this Contract (Inert) (m3)
|
0.991
|
Within the Contract working site
|
|
Reused
in other Projects (Inert) (m3)
|
0
|
-
|
|
Disposal
as Public Fill (Inert) (m3)
|
21.989
|
Tuen Mun Area 38
|
Table 9-2 Summary
of Quantities of C&D Wastes
|
Type of Waste
|
Quantity
|
Disposal Location
|
|
|
0
|
-
|
|
Recycled Paper / Cardboard Packing (kg)
|
0
|
-
|
|
Recycled Plastic (kg)
|
0
|
-
|
|
Chemical Wastes (kg)
|
0
|
-
|
|
General Refuses (m3)
|
0.075
|
NENT
Landfill
|
9.2.3
Since
canteen and/or kitchen are not allowed setting on the Project site,
no domestic wastewater was
generated from the Project.
10.1.1
According
to the approved Environmental Monitoring and Audit Manual, environmental site
inspection should be
formulated
by the ET
Leader. Regular
environmental site inspections shall be carried out to assess the environmental performance once per week.
10.2.1
In the Reporting Period, joint site inspections to
evaluate the site environmental performance carried out by the RE, ET and the
Contractor was on 6, 13, 20 and
27 September 2018. Moreover, IEC attended a joint site inspection on 13 September 2018. No non-compliance was noted.
10.2.2
The findings / deficiencies that observed during the weekly site
inspection are listed in Table 10-1.
Table 10-1 Site Observations
for the Works of Contract-1
|
Date
|
Findings / Deficiencies
|
Follow-Up Status
|
|
31 August 2018 (last Reporting Month)
|
Ÿ
Insufficient
capacity of silt trap at the drainage channel was observed. The Contractor
should increase the capacity of the desilting facilities (e.g. add sedimentation
tank and WetSep) to ensure all the treated runoff fulfills the discharge requirement of the discharge licence.
|
Ÿ
A WetSep was
provided to increase the desilting capacity.
|
|
|
Ÿ
Soil
bund without proper covered was observed. The Contractor should cover the
soil bund with tarpaulin sheet to reduce runoff with high soil content
during rainy days.
|
Ÿ
The
soil bund was covered with tarpaulin sheet properly.
|
|
6 September 2018
|
Ÿ The Contractor should provide tree protection zone for
the retained tree on site.
|
Ÿ Tree protection zone was provided.
|
|
|
Ÿ
Chemcial
container without drip tray was observed located on site. The Contractor
should provide drip tray to aviod land contamination.
|
Ÿ Chemical container has been removed from site.
|
|
13 September 2018
|
Ÿ Chemcial
container without drip tray was
observed. The Contractor should provide drip tray underneath to aviod land
contamination.
|
Ÿ The chemical container has
been removed from site.
|
|
|
Ÿ
Generator without NRMM labelling was observed. The
Contractor should provided NRMM label
on the generator in accordance with the requirement of NRMM
regulation.
|
Ÿ NRMM label was not required
for generator less than 19 kW.
|
|
20 September 2018
|
Ÿ Oil
stains suspecting leaked from the
excavator was observed on ground. The Contractor was advised to
clean up the
oil stains and dispose as chemical wastes and maintain the excavation in good condition.
|
Ÿ The oil stains were cleared.
|
|
27 September 2018
|
Ÿ
No adverse environmental issue was observed.
|
Ÿ NA
|
10.2.3
The Contractor is reminded to cover the open slope
as far as practicable to reduce
turbid runoff generated during rainy days and ensure all site runoff are
properly diverted and treated prior to discharge.
Moreover, all temporary catchpits shall be maintained in good condition in order to reduce water
impact during heavy rainfall.
10.2.4
Moreover, removal of stagnant water within site areas should be conducted after rain to prevent mosquito breeding. In addition, all retained trees within site area shall be properly protected by mean of tree protection zone to avoid damage from work.
11.1.1
In
the Reporting Period, no
environmental complaint was
received. No summons and prosecution
was lodged for the Contract.
The
statistical summary table of the environmental complaint, summons and
prosecution are presented in Tables 11-1, 11-2 and 11-3.
Table
11-1 Statistical
Summary of Environmental Complaints
|
Reporting Period
|
Environmental Complaint
Statistics
|
|
Frequency
|
Cumulative
|
Complaint Nature
|
|
1 – 30 September 2018
|
0
|
0
|
NA
|
Table 11-2 Statistical
Summary of Environmental Summons
|
Reporting Period
|
Environmental Summons
Statistics
|
|
Frequency
|
Cumulative
|
Complaint Nature
|
|
1 – 30 September 2018
|
0
|
0
|
NA
|
Table 11-3 Statistical
Summary of Environmental Prosecution
|
Reporting Period
|
Environmental Prosecution
Statistics
|
|
Frequency
|
Cumulative
|
Complaint Nature
|
|
1 – 30 September 2018
|
0
|
0
|
NA
|
11.1.2
In addition, no complaints received and emergency
events relating to violation of environmental legislation for illegal dumping and landfilling
were received.
12.1.1
The environmental mitigation measures that recommended in the
Implementation Schedule for Environmental Mitigation Measures (ISEMM) in the
approved EM&A Manual covered the issues of dust, noise, water and waste and
they are summarized presented in Appendix N.
12.1.2
The Works of Contract 1 under the Project shall be implementing the required
environmental mitigation measures according to the approved EM&A Manual
subject to the site condition.
Environmental mitigation measures implemented in this Reporting Month is summarized in Table 12-1.
Table 12-1 Environmental
Mitigation Measures
|
Issues
|
Environmental Mitigation Measures
|
|
Water
Quality
|
·
Provided efficient silt removal facilities to reduce SS level before effluent
discharge.
·
Provided ditches, earth bunds or sand bag
barriers to minimize polluted runoff.
·
Temporary drainage was provided
to prevent runoff going through site
surface and minimize polluted runoff.
·
Provided perimeter cut-off drains at site
boundaries to intercept storm runoff from crossing the site.
·
Exposed slopes surface were compacted and covered with tarpaulin or similar means
·
Provided portable chemical toilets on site.
|
|
Air
Quality
|
·
Maintain damp /
wet surface on access road.
·
Maintain low vehicular speed within the works areas.
·
Provided vehicle wheel washing facilities at each
construction site exit;
·
Provided water spraying for all active works area.
·
Stockpiles
of dusty material were covered
with impervious sheeting.
·
Provided workers to clear dusty materials at the vehicle
entrance or exit regularly.
·
Stockpile more
than 20 bags of cement or dry pulverized fuel ash (PFA) has been covered entirely by impervious sheeting or placed in an
area sheltered on the top and the 3 sides.
|
|
Noise
|
·
Restricted operation time of plants from 07:00 to 19:00 on
any working day except for Public Holiday and Sunday.
·
Keep good
maintenance of plants
·
Placed noisy plants away from residence and school
·
Provided noise barriers or hoarding to enclose the noisy
plants or works
·
Shut down the
plants when not in used.
|
|
Waste
and Chemical Management
|
·
Provided on-site sorting prior to disposal
·
Followed requirements and procedures of the “Trip-ticket
System”
·
Predicted required quantity of concrete accurately
·
Collected the unused fresh concrete at designated
locations in the sites for subsequent disposal
|
|
General
|
·
The site was
generally kept tidy and clean.
|
12.2.1 According to the information provided by HCTYJV, the
forthcoming construction activities for Contract 1
are listed below:
(i)
General
Site Clearance
(ii)
Bulk
Excavation
(iii)
Construction
of fill slope and surface channel
(iv)
Construction
of Cut Slope, installation of soil nailing and construction of surface channel
(v)
Sheetpiling
works for retaining wall
(vi)
Construction
of retaining wall
12.3.1
Key
issues to be considered in the coming month for the works of Contract 1 include:
Ÿ Implementation of control measures for
rainstorm;
Ÿ Regular clearance of stagnant water during
wet season;
Ÿ Implementation of dust suppression measures
at all times;
Ÿ Potential wastewater quality impact due to
surface runoff;
Ÿ Potential fugitive dust quality impact due
from the dry/loose/exposure soil surface/dusty material;
Ÿ Ensure dust suppression measures are
implemented properly;
Ÿ Sediment catch-pits and silt removal
facilities should be regularly maintained;
Ÿ Discharge of site effluent to the nearby
wetland is prohibited;
Ÿ Nearby wetland prohibited stockpiling
and/or disposal of materials;
Ÿ Follow-up of improvement on general waste
management issues; and
Ÿ Implementation of construction noise
preventative control measures.
13.1.1
This
is the 2nd
monthly Environmental Monitoring and Audit Report presenting the
monitoring results and inspection findings for the period of 1 to 30 September 2018.
13.1.2
No
24-hour or 1-hour TSP monitoring result that triggered the Action or Limit
Levels was
recorded. No NOEs or the associated
corrective action was therefore required.
13.1.3
No
noise complaint (which is an Action Level exceedance) was received and no construction
noise measurement result that exceeded the Limit Level was recorded in this Reporting Month. No NOEs or the associated corrective actions
were therefore issued.
13.1.4
For water quality monitoring, a total of 18
Limit Level (LL) exceedances, including 12 LL exceedance of turbidity and 6 LL exceedances of
SS were recorded at designated monitoring location M3. Investigation results revealed that
water quality mitigation measures have been implemented to minimize the
water quality impact arising from contract works. Such as temporary bund and de-silting trench were
installed at Retaining Wall RW1 to reduce the suspended solids content in
runoff. Series of sheet pile was
installed at site boundary to prevent site runoff flowing to the Conservation
Area (CA). Moreover, exposed surface were covered by tarpaulin
sheet as far as practicable. It was
observed that construction of temporary drainage system
was on-going and no muddy
discharge was observed. Since there were continuous rainstorms which affecting the water quality of seasonal river
course and the pond of M3 is a catchment of rainwater, it
is concluded
that the exceedances were related to
the impact of rain and unlikely caused by the works under the
Contract 1.
13.1.5
Monthly ecological
monitoring for
sensitive habitat is undertaken on 11th September 2018. Moreover, Landscape and visual inspection was undertaken by the
RLA on 28th
September 2018.
13.1.6
In the Reporting Period, no environmental complaint, summons and prosecution was received. In addition, no complaints received and emergency events relating to
violation of environmental legislation for illegal dumping and landfilling
were received.
13.1.7
In the Reporting Period, joint site inspections to
evaluate the site environmental performance were carried out by the RE, ET and the Contractor on 6th,
13th, 20th and 27th September 2018 and IEC attended joint site inspection on 13th September 2018. No
non-compliance of environmental issue was recorded.
In general, it was reminded that
water quality mitigation measures should be fully implemented and good housekeeping practice should be
maintained.
13.2.1
The Contractors should pay special
attention on water quality mitigation measures and fully implement according
to the ISEMM of the EM&A Manual, in particular in rainy season to
prevent surface runoff with high SS content and other pollutants from flowing
to local steam and Conservation Area (CA).
13.2.2
Construction
noise would be a key environmental issue during construction phase of the Project. Noise mitigation measures such as using
quiet plants and mobile noise barriers should be implemented in accordance with
the EM&A requirement.
13.2.3
Since
construction site under the Works of Contract 1 of the Project is located near villages, HCTYJV should
fully implement air quality mitigation measures to reduce construction dust
emission.
13.2.4
Furthermore,
daily cleaning and weekly tidiness shall be properly performed and maintained.
In addition, mosquito control should be
performed to prevent mosquito breeding on site.
